    UNV IPC3224SS-ADF28K-I1 download pdf for UNV  IPC3224SS-ADF28K-I1

    UNV - 2x 4MP Dual-channel Non-Splicing Multiview Series IR Fixed Intelligent IP Camera, 1/3" 4MP PS CMOS, Ultra 265/H.264/MJPEG, AI Human/Vehicle Detection features, max 25fps@4.0M(2688x1520), 2x2.8mm lens, IR Distance up to 98 feet, 130dB Optical WDR, Micro SD up to 256GB, Built-in Microphone, Audio I/O, Alarm I/O, DC12V, PoE (up to 9.1W), IK10, IP67, NDAA.

    UNV logo
    UNV  IPC3224SS-ADF28K-I1

    Thumbnail Filmstrip of UNV IPC3224SS-ADF28K-I1 Images

      Purchase UNV IPC3224SS-ADF28K-I1

      SKU: 3224SSADF28KI1
      UNV IPC3224SS-ADF28K-I1

      Please sign in to purchase.


      Specifications

      UNV  2*4MP Dual-channel Non-Splicing Multiview Series IR Fixed Intelligent Network Camera

      Key Features:

      • High quality image with 2*4MP resolution, 1/3.0"CMOS sensor
      • Single IP with dual channels
      • 4MP (2688*1520)@25/20fps; 4MP(2560*1440)@25/20fps; 3MP(2304*1296) @30/25fps;2MP(1920*1080)@30/25fps
      • Ultra 265, H.264,H.265, MJPEG
      • Both channels support intelligent perimeter protection, include cross line, intrusion, enter area, leave area detection
      • Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and motor vehicle and non-motor vehicle
      • Intelligent People Flow Counting and Crowd Density Monitoring (Only Channel 1)
      • 130dB true WDR technology enables clear image in strong light scene
      • Built-in two Mics
      • Supports 256 GB Micro SD card
      • DC12V or PoE(IEEE 802.3af) power supply
      • IP67 protection and IK10 vandal resistant
      • 3-Axis
