Uniview EK-S31P8DLT46T2

Specifications

Uniview  EK-S31P8DLT46T2  8-ch 4K NVR + 2TB HDD with 6x 4MP WDR IR Eyeball Network Cameras

 4-ch 4K NVR + 2TB HDD with 6x 4MP WDR IR Eyeball Network Cameras. NVR:Support Ultra 265/H.265/H.264 video formats, 4/8/16-channel input, Plug & Play with 4/8 independent PoE network interfaces, Support 1-ch HDMI, 1-ch VGA, HDMI up to 4K (3840x2160) resolution, HDMI and VGA simultaneous output, Up to 4K resolution recording, Support cloud upgrade, up to 10TB HDD, DC 48 V/1.35 A, = 9W. Camera: High quality image with 4 MP, 1/3.0" CMOS sensor, 4 MP (2560 × 1440)@25/20 fps; 3 MP (2304 × 1296)@30/25 fps; 1080P (1920 × 1080)@30/25 fps; 720P (1280 × 720)@30/25 fps, Ultra 265, H.265, H.264, MJPEG, Smart IR, up to 30 m (98.4 ft) IR distance, MicroSD, up to 512 GB, Supports PoE power supply, 3-axis, 2.8mm focal length, G.711U, G.711A, DC 12 V±25%, PoE (IEEE 802.3af) Power consumption: Max. 7.0 W.

NVR301-08S3-P8 Features:

• Support Ultra 265/H.265/H.264 video formats

• 4/8/16-channel input
• Plug & Play with 4/8 independent PoE network interfaces
• Support 1-ch HDMI, 1-ch VGA, HDMI up to 4K (3840x2160) resolution
• HDMI and VGA simultaneous output
• Up to 4K resolution recording
• Support cloud upgrade
• G.711A, G.711U
• 21 languages
• 1 SATA interface up to 10TB
• DC 52 V/1.8 A
• Max 30 W for single port, Max 75 W in total

• High quality image with 4 MP, 1/3.0" CMOS sensor
• 4 MP (2560 × 1440)@25/20 fps; 3 MP (2304 × 1296)@30/25 fps; 1080P (1920 × 1080)@30/25 fps; 720P (1280 × 720)@30/25 fps
• Ultra 265, H.265, H.264, MJPEG
• Smart IR, up to 30 m (98.4 ft) IR distance
• MicroSD, up to 512 GB
• Supports PoE power supply
• 3-axis
• 2.8mm focal length
• Distance (Detect)        63.0 m (206.7 ft)
• Distance (Observe)     25.2 m (82.7 ft)
• Distance (Recognize) 12.6 m (41.3 ft)
• Distance (Identify)       6.3 m (20.7 ft)
• G.711U, G.711A
• DC 12 V±25%, PoE (IEEE 802.3af)
• Power consumption: Max. 7.0 W
