IC Realtime IPEL-F12F-IRW2
IC Realtime - 12MP IP Indoor/Outdoor Fisheye Dome Camera, 1.85mm Fisheye Lens (360 AOV) 33 ft IR Built in Microphone, 12VDC/POE, AI, 256Gb SD slot, IVS: Tripwire, Heat Map, H.265. 10 Year Limited Warranty.
Thumbnail Filmstrip of IC Realtime IPEL-F12F-IRW2 Images
Specifications
IC Realtime - IPEL-F12F-IRW2 - 12MP Panoramic Network IR Fisheye Camera
IC Realtime's latest 12MP IR fisheye IP camera is the best
all-around security camera ever made. IPEL-F12F-IRW2 delivers a real-time, 12MP
simultaneous view & recording over a massive 360° observation area that can
be "de-warped" into a standard flat view for review or direct
real-time situational awareness. This latest IRW2 version adds a dual
microphone audio pickup array/speaker combination and our latest FlexSmartAi
built-in intelligence features, making IPEL-F12F-IRW2 the industry's smartest
wide-area camera choice.
THE ALL-SEEING "SKY EYE"
Developed as a single point, 360° coverage tool, this single-camera location
will see & hear everything around it - all at the same time - in each video
frame. This 360° "fisheye" frame with simultaneous audio capture
makes IPEL-F12F a unique & invaluable resource for complete area audio
& video awareness. This special wide-area video & audio coverage
provides situational context for retail loss management, detention area
overwatch, and a bird's eye perspective for production area oversight in
manufacturing & fulfillment supervision. IPEL-F12F's tough IK10 impact
resistance and IP67 weather rating & internal heater mean it can perform in
challenging areas such as school lunchrooms, parking lots, or public spaces
like entrance plazas & lobby areas.
12MP PUT TO WORK
IPEL-F12F-IRW2's 12MP IR Fisheye network camera stream utilizes a densely
packed 4000 x 3000-pixel video sensor. This density renders incredibly detailed
native 360° fisheye views using the camera's 1.85mm spherical aspect fixed
focus lens system, supplemented under 0.01 lux ambient light by 32+ feet of IR
illumination. That ultra-detailed 360° stream is then electronically de-warped
as desired into standard camera views for human observation & analysis -
and for the camera's own even more unblinking & perceptive FlexSmartAI
detection system.
THE BEST USE FOR POE & AI
Artificial Intelligence is at its best when working on tasks that require
detailed & unwavering 24/7 attention. Humans find it hard to do, making IC
Realtime's IPEL-F12F-IRW2 the best in the business. It has the most advanced AI
skill set in the industry - FlexSmartAI. The system’s algorithm-enhanced motion
detection capabilities are excellent right out of the box, and the system's
deep learning capability means they will learn & get better over time. They
include IVS Perimeter protection with customizable tripwire & intrusion
zones, Heat Mapping, People Counting, and even Queue (people in line)
management & alerts. The camera can even directly display & export
custom human traffic reports.
UNDENIABLE RECORDS
For comprehensive forensic review, no other technology can equal the
IPEL-F12F's ability to simultaneously see & record everything that happens
across an entire area, providing objective, undeniable eye-witness evidence.
This 12MP fisheye camera captures and replays high-definition audio and video.
The live or recorded stream can be electronically de-warped into standard flat
video frame views to observe any specific area. When the camera's legally
permissible, time-stamped video watermarks are enabled, video & audio
evidence from the IPEL-F12F's is virtually undeniable.
PART OF THE TEAM
Built as a team player, IPEL-F12F-IRW2 shares this AV & detection
datastream with its paired FlexSmartAI NVR. When installed with one of our
state-of-the-art FlexSmartAi NVRs, the IPEL-F12F-IRW2 and NVR form an
interactive video/audio system to become the most flexible, complete, and
cost-effective AI analysis system available today.
It's hard to overstate the advantages of live audio & video oversight and
time-stamped recorded digital records enabled by this revolutionary
single-point 360° view 12MP fisheye security camera. IPEL-F12F's ability to
see, hear, capture, and even verbally interact with a wide area cannot be
duplicated with any other technology. 360° video, alarm ports, audio I/O jacks,
dual-mic audio pickup, and a built-in interactive talkback speaker make this
unique IP camera an irreplaceable addition to any IP video system.
Key
Features:
- 1/1.7” 12MP progressive scan STARVIS™ CMOS
- H.265/H.264 triple-stream encoding
- Max 25fps@12M(4000x3000), 8M(3280 × 2480)@25/30 fps
- Multiple dewarped Modes
- Day/Night(ICR), 3DNR, AWB, AGC, BLC
- Perimeter Protection, People Counting, Heat Map
- Max. IR LEDs length 33ft
- Built-in dual array Microphone and speaker, Micro SD memory, IP67, IK10, PoE
True Day/Night
A day/night mechanical IR cut filter makes this camera ideal for
applications with fluctuating lighting conditions, delivering color
images during the day and automatically switching to
monochrome as the scene darkens.
Dewarping Mode
Fisheye dewarping solves the problem of distortion in the circular
panoramic view. The camera offers multiple dewarping modes for
different installations and configurations, either with an AVR, NVR
or, via the Web interface. Each dewarping mode offers options to
adjust each scene.
Advanced Intelligence (Heatmap)
In addition to the basic IVS functions, such as Tripwires and
Intrusion Zones, this camera also supports more advanced IVS
solutions. Heat Maps will overlay different ‘thermographic’ colors
depending on activity levels in a region ranging from blue to red.
Heat Mapping provides essential analytic data for a variety of
business applications by keeping track of key crowd density
statistics.
Smart IR
With IR illumination, detailed images can be captured in low light
or total darkness. The camera's Smart IR technology adjusts the
intensity of camera's infrared LEDs to compensate the distance of
an object. Smart IR technology prevents IR LEDs from whitening
out images as they come closer to the camera. The camera's
integrated infrared illumination provides high performance in
extreme low-light environments up to 10m (33ft).
HEVC(H.265)
H.265 ITU-T VCEG is a new video coding standard. H.265
Following standard developed around the existing video coding
standard H.264 , some retain the original technology , while some
of the relevant technology to improve the new technology uses
advanced technology to improve the relationship between the
code stream , encoding quality , and the delay between algorithm
complexity , optimize settings specific contents include : Improve
compression efficiency , improve the robustness and error recovery
capabilities, real-time to reduce the delay, reduce channel
acquisition time and a random access delay , reduce complexity ,
etc.
Protection (IP67, IK10, wide voltage)
Supporting ±25% input voltage tolerance, this camera suits even
the most unstable conditions for outdoor applications. Its 6KV
lightning rating provides effective protection for both the camera
and its structure against lightning. IP67 is supported by the
camera, which makes it suitable for both indoor and outdoor
environments. IK10 compliance enables the camera to sustain the
equivalent of 5kg (11.02lbs) force.
