    Dahua 22204UENI download pdf for Dahua  22204UENI

    Dahua - 2MP Mini Starlight PTZ IP Camera, 1/2.8-in. 2MP STARVIS CMOS Sensor, 2D/3D DNR, ICR, True WDR, 1080p at 30fps, 2.7~11mm Vari-Focal Lens, Starlight Technology for Ultra-low Light Sensitivity, H.265/H.264/MJPEG, Micro SD Card Slot Up to 128 GB, IP66/IK10, Optical Zoom:4X, 12 VDC/1.5 A/PoE.

    Dahua logo
    Dahua  22204UENI

    Thumbnail Filmstrip of Dahua 22204UENI Images

      Purchase Dahua 22204UENI

      SKU: 22204UENI
      Dahua 22204UENI

      Please sign in to purchase.


      Dahua 2MP Mini PTZ Network Camera

      The 2 MP Starlight Mini PTZ Dome camera features a 1/2.8-in. STARVIS™ CMOS imager with a 4x optical zoom lens, and provides an all in one solution for capturing video surveillance for indoor and outdoor applications. The camera uses the H.265 video compression standard to improve encoding efficiency while preserving high-quality video. The PTZ camera is equipped with quick and accurate pan/tilt/zoom control and True Wide Dynamic Range for applications with direct sunlight or glare.

      Key Features:

      • 1/2.8-in. 2MP STARVIS™ CMOS Sensor
      • 1080p at 30 fps Maximum Resolution
      • H.265 and H.264 Dual Codecs
      • 2.7 mm to 11 mm, 4x Optical Zoom
      • Triple-stream Encoding
      • Starlight Technology for Ultra-low Light Sensitivity
      • True Wide Dynamic Range (120 dB)
      • Intelligent Video System (IVS)
      • IP66 Ingress Protection and IK10 Vandal Resistance
      • PoE Support
      Starlight Technology

      For challenging low-light applications, Dahua’s Starlight Ultra-low Light Technology offers best-in-class light sensitivity, capturing color details in low light down to 0.005 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.

      Intelligent Video System

      IVS is a built-in video analytic algorithm that delivers intelligent functions to monitor a scene for Tripwire violations, intrusion detection, and abandoned or missing objects. A camera with IVS quickly and accurately responds to monitoring events in a specific area. In addition to scene analytics, the camera offers tamper detection by recognizing a dramatic scene change and generating a warning message to inspect the camera.

      Wide Dynamic Range

      The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.

      High Efficiency Video Coding (H.265)

      The H.265 (ITU-T VCEG) video compression standard offers double the data compression ratio at the same level of video quality, or substantially improved video quality at the same bit rate, as compared to older video compression technologies. H.265 offers such impressive compression by expanding the pattern comparison and difference-coding, improving motion vector prediction and motion region merging, and incorporating an additional filtering step called sample-adaptive offset filtering.


      The camera conforms to the ONVIF (Open Network Video Interface Forum) and to the PSIA (Physical Security Interoperability Alliance) specifications, ensuring interoperability between network video products regardless of manufacturer.


      With a temperature range of –30 °C to +60 °C (–22 °F to 140 °F), the camera is designed for extreme temperature environments. The camera complies with an IK10 vandal resistance rating making it capable of withstanding the equivalent of 5 kg (11.02 lbs) of force dropped from a height of 40 cm (15.75 in.). Subjected and certified to rigorous dust and water immersion tests, the IP66 rating makes it suitable for demanding outdoor applications.
