UNV IPC6434LR-X16-VG1

Specifications

UNV - IPC6434LR-X16-VG1  4MP 16X LightHunter Network PTZ Dome Camera Datasheet

UNV IP PTZ, LightHunter, 1/2.9" 4MP PS CMOS, 30fps@4MP(2688x1520), 16X (5.5-88mm), 328ft IR, 0.005Lux, Micro SD (512GB), Audio I/O, Alarm I/O, DC12V (23W), POE+ (IEEE 802.3at), IK10, IP66. Compatible with: TR-JB04-D-IN, TR-FM180-IN, TR-UF45-F-IN, TR-WE45-IN, TR-CE45-IN, TR-JB12-IN, TR-UP08-A-IN, TR-UC08-A-IN

Key Features:

• High quality image with 4 MP, 1/2.9" CMOS sensor
• 2688 × 1520@30 fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• Dual streams
• 16X optical zoom
• 5.5mm to 88mm focal length
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 100 m (328 ft.) IR distance
• DC 12 V±10%, PoE+ (IEEE 802.3at)
• Max 23.0 W
• Alarm I/O: 2/1, audio I/O: 1/1
• IP66 ingress protection
• IK10 vandal resistant

The main goal of video surveillance is to see clearly anytime, anywhere. Cameras need to be well prepared for providing high-resolution and colorful images in different light conditions. The LightHunter Technology is an innovative technology that delivers vivid color, appropriate brightness, and extremely clear images in ultra-low light. LightHunter Technology significantly improves the image brightness with F1.6 Large Iris design & BSI sensor. With the specially designed large size sensors, the IPCs have higher photosensitivity, and feature high SNR. UNV's uniquely patented technology U-ISP improves the definition and brightness of images. U-ISP features a new generation of noise reduction technology to improve Signal-Noise Ratio and reduce blur. It effectively reduces blur during objects moving, which ensures that the image is restored to the true scene. Combine hardware and software advantages, LightHunter Technology guarantees the image full of color under ultra-low light.
