Specifications

Uniview  XVR301-04G3  1 HDD 4-ch DVR

1 HDD 4-Ch 1U Digital Video Recorder, Support H.265/H.264 video formats, Support audio over coaxial cable (only for TVI cameras), Control the dual-light of UNV analog cameras under TVI, Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access, 4-channel BNC input, Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080, HDMI and VGA simultaneous output, Long transmission distance over coaxial cable, Support mainstream cameras of ONVIF and RTSP protocols, Analog: 2 x 5MP Lite@12, 2 x 4MP Lite@15, 2 x 1080P@15, IP: 1 x 4MP@30, 2 x 1080P@30, Ultra Motion Detection (UMD), 20 languages, 1 HDD up to 16 TB, DC 12 V/2 A, = 8W.

Key Features:

• Support H.265/H.264 video formats

• Support audio over coaxial cable (only for TVI cameras)

• Control the dual-light of UNV analog cameras under TVI

• Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access

• 4-channel BNC input

• Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080

• HDMI and VGA simultaneous output

• Long transmission distance over coaxial cable

• Support mainstream cameras of ONVIF and RTSP protocols

• HDMI: 1920 × 1080/60 Hz
• 5MP Lite/4MP Lite/1080P/720P/D1
• Main stream: 1080P@15fps Sub stream: D1@15fps
• Analog: 2 x 5MP Lite@12, 2 x 4MP Lite@15, 2 x 1080P@15
• IP: 1 x 4MP@30, 2 x 1080P@30
• 16Mbps (Up to 24Mbps after all analog channel conversion)
• 48Mbps
• 128 remote users
• 20 languages
• 1 SATA up to 16TB
• DC 12 V/2 A
• ≤ 8W
