TRENDnet TI-G162

Specifications

TRENDnet 16-Port Industrial Gigabit DIN-Rail Switch

TRENDnet’s Industrial Gigabit DIN-Rail Switches are reliable and rugged networking solutions that are designed for use in both extreme and demanding environments. Each Industrial Gigabit DIN-Rail Switch features a rugged IP30 rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating in both high and low temperatures for industrial environments within -40° – 75° C (-40° – 167° F). Our hardened industrial switch models feature copper Gigabit ports for high-speed device connections, and Gigabit SFP slots that supports 1000Base-FX modules for long distance fiber networking applications.

Key Features:

• 14 x Gigabit ports
• 2 x Gigabit SFP slots
• 32Gbps switching capacity
• Hardened IP30 rated metal switch
• Includes DIN-Rail mount and wall mount brackets
• Wide operating temperature range of -40° – 75°C (-40° – 167°F)
• Multiple power inputs provide redundant power with overload current protection
• Alarm output triggered by power failure
• Power supply sold separately (model: TI-M6024)
• Lifetime Warranty


Gigabit Ports

Industrial switch features copper Gigabit ports for high-speed device connections, and Gigabit SFP slots that supports 1000Base-FX modules for long distance fiber networking applications

Alarm Relay

Hardened industrial switches each with an alarm relay triggered by power failure of primary and/or redundant power

Shock and Vibration Resistant

Rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6)

DIN-Rail / Wall Mounts

IP30 rated metal enclosure on the industrial switch with included DIN-Rail mount and wall mount hardware

Din-rail Mount

Metal enclosure with integrated DIN-rail mount

Jumbo Frame

Supports larger packets, or Jumbo Frames (up to 9KB), for increased performance

Electro Magnetic Compliance

Complies with industrial EMS certifications (IEC 61000-4-2) ESD: Contact: 6kV | Air: 8kV, (IEC 61000-4-4) EFT: Power: 2kV | Signal: 2kV, (61000-4-5) Surge: Power: 2kV | Signal: 2kV

Redundant Power

Multiple power inputs provide redundant power with overload current protection (power supply sold separately, model: TI-M6024)

Wide Temperature Range

A wide operating temperature range of-40° – 75° C (-40° – 167° F) allows for the installations of the industrial switches in environments with extreme hot or cold conditions

Grounding Point

Industrial switches feature a grounding point for protection against external electrical surges
