Trendnet TEG-10GBSR

Specifications

TRENDnet 10GBASE-SR SFP+ Multi Mode LC Module 300 m (984 feet) with DDM

TRENDnet's hot-pluggable TEG-10GBSR, 10GBASE-SR SFP+ Multi Mode LC Module, works with a MSA compliant SFP+ slot. This Multi Mode transceiver spans distances up to 300 meters (984 feet), comes with a LC duplex connector, and supports up to 10.5 Gbps networking throughput speeds. Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/ receive power, temperature, and voltage.

Key Features:

• Hot-pluggable SFP+ transceiver
• SFP+ MSA compliant
• Supported throughput up to 10.5 Gbps
• Multi Mode fiber for distances up to 300 m (984 feet)
• 850 nm wavelength
• Duplex LC connector
• Digital Diagnostics Monitoring (DDM) support
• Operating temperature: 0 to 70 °C (32 to 158 °F)
• Single 3.3 V power supply
• Lifetime Warranty
• NDAA / TAA compliant (U.S. and Canada only)


Hot-Pluggable SFP+

Hot-pluggable SFP+ transceiver works with a MSA compliant SFP+ slot

Fiber Port

LC-type duplex connector

Operating Temperature

Rated for an operating temperature range of 0 to 70 °C (32 to 158 °F)

Fiber Wavelength

Compatible with Multi Mode 850 nm transmissions

DDM Support

Digital Diagnostics Monitoring (DDM) captures critical device parameters such as transmit/ receive power, temperature, and voltage

Standards

Compliant with SFF-8431, SFF-8432, SFF-8472, FC-PI-4,10G FC, and IEEE802.3ae 10GBASESR

Fiber Distance

Supports networking for distances up to 300 meters (984 feet)

Power Supply

Single 3.3 volt power supply
