IC Realtime - HDEG-E80F-DI-M1 - 8MP HDAVS Indoor/Outdoor Mini Eyeball Dome Camera
Introducing the latest addition to IC Realtime’s Edge lineup—the HDEG-E80F-DI-M1 Coaxial AVS Eyeball Turret Camera. This cutting-edge camera combines 4K resolution and Smart Dual Illumination to deliver a superior surveillance experience. At the core of the HDEG-E80F-DI-M1 is its advanced 4K CMOS image sensor, which provides unparalleled image clarity and definition, even in low-light conditions. With an 8MP resolution (3840 × 2160) at 15 frames per second, this camera ensures every detail is captured. The 2.8mm fixed lens offers an impressive 106° angle of view, and the compact dimensions of 3.70" × 3.37" make it a perfect fit for various installation environments.
The camera’s Smart Dual Illumination technology sets it apart, featuring both IR and warm light LEDs for dynamic lighting solutions. In standard low-light scenarios, the camera operates in IR mode for discreet monitoring. When a target is detected using IC Realtime’s HDVR Intelligence, the camera seamlessly switches to white light illumination, delivering up to 65 feet of vivid, full-color footage even in the darkest conditions.
Engineered to excel in challenging environments, the HDEG-E80F-DI-M1 boasts 120dB WDR (Wide Dynamic Range) and HLC-Pro with Super Adapt, ensuring optimal image quality regardless of lighting complexities. Its IP67 rating guarantees exceptional durability, making it resistant to dust and water. Additionally, a built-in microphone captures high-quality audio for enhanced situational awareness. The camera supports multiple video output formats—AVS, TVI, AHD, and CVBS—via a single BNC port, providing versatile integration options. Powering the HDEG-E80F-DI-M1 is a reliable 12V DC supply with ±30% tolerance, ensuring consistent performance. When paired with IC Realtime’s HDVR systems, this camera becomes a gateway to advanced surveillance features, including seamless integration with the IC Now desktop platform and the IC View+ mobile app for iOS and Android. This compatibility allows for flexible monitoring and management from virtually anywhere. Backed by a robust 7-year warranty and outstanding U.S.-based technical support, the HDEG-E80F-DI-M1 represents a new standard in reliability and innovation for professional security solutions. Elevate your surveillance capabilities with IC Realtime.
Key
Features:
4K CMOS
- Focal Length: 2.8mm
- Progressive scanning system
- Up to 65.62ft. white light illumination distance
- DC 12V ±30%
- Max 5.7W
- IP67
- Mounting Pan/Tilt/Rotation: Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
3DNR is noise reduction technology that detects and
eliminates random noises by comparing two sequential frames. IC Realtime’s
advanced 3DNR technology allows remarkable noise reduction with little impact
to sharpness, especially under limited lighting conditions. 3DNR also
effectively decreases the required bandwidth and helps lower storage space
requirements.
