    Geovision GV-TDR4803-2F download pdf for Geovision  GV-TDR4803-2F

    Geovision - AI 4MP H.265 Super Low Lux WDR Pro IR Mini Fixed Rugged IP Dome, 1/3" progressive scan super low lux CMOS sensor, H.265/H.264/MJPEG, 0 Lux with IR on, 2.8mm Fixed Lens, WDR Pro, ICR, Up to 30 fps at 2688 x 1520, Built-in micro SD card slot (SD / SDHC / SDXC / UHS-I, Class 10) for local storage, Two - way audio, IP67/IK10, IR Range up to 100ft, DC 12V / PoE.

    Geovision logo
    Geovision  GV-TDR4803-2F

    Thumbnail Filmstrip of Geovision GV-TDR4803-2F Images

      Purchase Geovision GV-TDR4803-2F

      SKU: GVTDR48032F

      MSRP: $248.00

      Available





      Specifications

      Geovision AI 4MP H.265 Super Low Lux WDR Pro IR Mini Fixed Rugged IP Dome

      GV-TDR4803 is an outdoor, fixed, network camera equipped with an automatic IR-cut filter and an IR LED for day and night surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. The camera adheres to IP67 and IK10 standards, and can be powered through PoE.  Empowered by deep learning algorithms, AI technology distinguishes human and vehicles from other moving objects. Integrated with GeoVision Video Management Software (VMS), it supports AI perimeter protection, real time alert, events playback and more.

      Key Features:

      • AI deep learning: AI Perimeter Protection & Classification (Human, Vehicle)
      • 1/3" progressive scan super low lux CMOS sensor
      • Min. illumination at 0.003 lux
      • Triple streams from H.265, H.264 or MJPEG
      • Wide Dynamic Range Pro (WDR Pro)
      • Up to 30 fps at 2688 x 1520
      • Intelligent IR
      • Day and night function (with removable IR-cut filter)
      • IR distance up to 30 m (100 ft)
      • Built-in micro SD card slot (SD / SDHC / SDXC / UHS-I, Class 10) for local storage
      • 3-axis mechanism (pan / tilt / rotate)
      • Ingress protection (IP67)
      • Vandal Resistance (IK10)
      • Two-way audio
      • DC 12V / PoE (IEEE 802.3af)
      • ONVIF (Profile G, S, T) conformant
      Deep Learning Function

      • Face Detection
      • AI Perimeter Protection People Counting  (Intrusion, Crossing Line Entering Area, Leaving Area)
      • People Counting
