    Dahua DHI-EVS5016S-R download pdf for Dahua  DHI-EVS5016S-R

    Dahua - 16 HDD Enterprise Video Storage, 16 HDDs (Up to 8 TB Each), SAS/SATA, Hot-Swap, 320 Channels @ 2 Mbps Video Recording Plus, RAID 0/1/3/4/5/6/10/50/60 (Enterprise-level HDDs are recommended), JBOD, Hotspare, USB Device, Network, eSATA Device, 100 VAC to 240 VAC, 47 to 63 Hz, 1 + 1 Redundant Power, < 200 W (with HDD).

    Dahua logo
    Dahua  DHI-EVS5016S-R

    Thumbnail Filmstrip of Dahua DHI-EVS5016S-R Images

      Purchase Dahua DHI-EVS5016S-R

      SKU: EVS5016SR
      Dahua DHI-EVS5016S-R

      Please sign in to purchase.


      Dahua 16 HDD Enterprise Video Storage

      The EVS5016S-R Enterprise Video Storage device offers unparalleled storage technology. It is designed and developed to meet the needs of medium-range to high-end IP video surveillance applications; and supports 512 IP camera channels with 1024 Mbps incoming/recording/ forwarding bandwidth. Combined with hot-swap power supplies, fans, and hard disk drives, the EVS offers Enterprise Class availability. This EVS is ideal for a wide range of applications including public safety, transportation, government institutions, hotels, shopping malls, city centers, and financial institutions that demand flexibility, reliability, and centralized storage management. This EVS is compatible with numerous third-party devices making it the perfect solution for surveillance systems with or without a video management system (VMS). Its open architecture supports multi-user access and is compatible with ONVIF 2.4.

      Key Features:

      • High-performance Intel Processor
      • 320 Channels at 2 Mbps Video Recording plus  160 Channels Video Transfer, maximum (Dahua Protocol)
      • 640 Mbps Incoming/Recording Bandwidth, maximum
      • 16 HDDs, SAS/SATA, Hot-Swap
      • Supports RAID 0/1/3/4/5/6/10/50/60/JBOD, Hotspare
      • Supports Standard iSCSI Protocol for Expanded Storage Space
      • Modular Design
      • Redundant Power
      Modular Design

      The Enterprise Video Storage is rack mountable and designed to manage up to 76 channels of digital video for scalability. Powered by Intel® technology, the unit features dual redundant power supplies and a hot-swappable configuration to ensure stability.

      Storage Extension Capacity

      Local extension, connect to ESS extension storage by mini SAS interface. Extension storage support redundant power and RAID.

      RAID Support

      The Enterprise Video Storage device provides the processor and RAID enclosure in one chassis, resulting in both space and cost savings. RAID 0/1/3/4/5/6/10/50/60 support is available through a hardware-based RAID controller that removes the loading on the processor that software RAID can bring. A convenient web browser interface is used to manage the RAID controller.

      Video Recording Capability

      The Enterprise Video Storage device not only stores video data but is capable of simultaneous record, playback, live view and transmission of IP video. The device records 320 channels at 2 Mbps plus 160 channels of video transfer.

      N+M Hot Standby

      The highly reliable redundancy N+M Hot Standby design provides a secure, failover technique ensuring immediate backup. In the event of a system failure, the slave instantly takes over the master ensuring no data is lost.

      Automatic Network Replenishment (ANR) Technology

      Video storage devices with the ANR function automatically store video data on an IP camera SD card when the network is disconnected. After recovery of the network, the NVR automatically retrieves the video data stored on the camera.


      The EVS conforms to the ONVIF (Open Network Video Interface Forum) and to the CGI specifications, ensuring interoperability between network video products regardless of manufacturer.


      The storage device features a wide operating temperature range of  0° C to +40° C (+32° F to +104° F) and a working altitude range of 60 m below sea level to 5000 m above (196.85 ft to 16,404.20 ft).
