    Dahua A22DJ62 download pdf for Dahua   A22DJ62

    Dahua - 2MP HDCVI Fixed Eyeball Camera, 1/2.8-in. 2 MP Progressive-scan CMOS Sensor, 0 lux at F1.6 with IR On, 1080p at 30 fps, 2.8 mm Fixed Lens, Supports Multiple Video Formats: HDCVI, CVBS, AHD and TVI, Built-in Microphone, IR Range up to 196.85ft, IP67, 12 VDC.

    Dahua logo
    Dahua   A22DJ62

    Thumbnail Filmstrip of Dahua A22DJ62 Images

      Purchase Dahua A22DJ62

      SKU: A22DJ62
      Dahua A22DJ62

      Please sign in to purchase.


      Dahua 2MP HDCVI Fixed Eyeball Camera

      Experience the superior clarity of Dahua's 2 MP HDCVI camera for vast coverage and superior image details. The 2 MP HDCVI series leverages existing coax infrastructures to deliver forensic-level images seamlessly and over long distances. The camera offers a 2.8 mm fixed lens, a multi-language On-screen Display, and HD/SD switchable output. The camera is ideal for hosting diverse applications — Starlight Technology and True Wide Dynamic Range allow the camera to operate in any lighting condition and the IP67 rating makes the camera suitable for the harshest environments.

      Key Features:

      • 1/2.8-in. 2 MP Progressive-scan CMOS Sensor
      • 2 MP (1920 x 1080) at 30 fps Maximum Resolution
      • 2.8 mm Fixed Lens
      • Starlight+ Technology for Low-light Applications
      • True Wide Dynamic Range (120 dB) and 3D Noise Reduction
      • ArcticPro Series Camera — Operational down to –40° C (–40° F)
      • Supports Multiple Video Formats: HDCVI, CVBS, AHD and TVI
      • HD or SD Output, Switchable
      • Built-in Microphone
      • Maximum IR Length 60 m (196.85 ft)
      • IP67 Ingress Protection
      Starlight Technology+

      For challenging low-light applications, Dahua’s Starlight low light Technology offers best-in-class light sensitivity, capturing details in low light applications. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.

      Three Signals over One Coaxial Cable

      HDCVI technology simultaneously transmits video, audio, and data over a single coaxial cable. Dual-way data transmission allows the HDCVI camera to communicate with an HCVR to send control signals or to trigger alarms.

      Long Distance Transmission

      HDCVI technology guarantees real-time transmission over long distances without loss of video quality. HDCVI cameras provide the same resolution as most IP network camera systems using existing RG-59, RG-6, or CAT 6 UTP cabling.


      HDCVI technology seamlessly integrates traditional analog surveillance systems with upgraded, high-quality HD video, making it the best choice to protect security investments. The plug and play approach enables full HD video surveillance without the hassles of configuring a network.

      Super Adapt

      The Super Adapt function is a built-in algorithm that automatically adjusts the camera's optical settings as environmental conditions change to produce optimal video quality. This function helps to make initial configuration easy since it does not require setting the optical settings manually once the camera is installed.

      Broadcast-quality Audio

      Audio information is used as supplementary evidence in video surveillance applications. This HDCVI camera transmits audio signals over the coaxial cable, eliminating the need for separate audio wiring. In addition, the camera uses unique audio processing and transmission technology that eliminates noise to best duplicate source audio, guaranteeing high-quality and highly effective audio information.

      Multiple-format Support

      The camera supports multiple video formats including, HDCVI, CVBS, AHD, and TVI. The camera can switch between these four formats via the switch located on the video output cable, making the camera compatible with not only HDCVI DVRs but also most existing HD/SD DVRs.

      True Wide Dynamic Range

      The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR optimizes both the bright and dark areas of a scene at the same time to provide usable video.


      The camera is subjected to rigorous dust and water immersion tests and certified to the IP67 Ingress Protection rating making it suitable for demanding outdoor applications. The camera allows for ±30% input voltage tolerance, suitable for the most unstable conditions for outdoor applications, and its 4KV lightning rating provides effective protection for both the camera and its structure against lightning.
